• This simple and affordable palletizer makes it easy to upgrade your hand palletizing operation, without losing the flexibility of manual palletizing. It eliminates the bending and lifting associated with manual palletizing, reducing the risk of back injuries and resulting high insurance premiums.
• Palletize cases, trays, display trays or totes
• Increase efficiency–product feed from any direction
• Eliminate bending and lifting to palletize cases
• Easily upgrade to automatic operation

An easy upgrade from manual palletizing

Operation is as simple as 1-2-3

1. Cases feed by conveyor and the operator slides them into the correct pattern.
2. When the layer is complete, the operator presses the start button, and the layer is automatically placed squarely on the previous pallet layer.
3. The table automatically returns to its original position for the next load.

Increase operator efficiency

No lifting, stooping or walking around the pallet. The operator simply transfers the product to the accumulation table, then presses the start button and the layer is lifted, squared, and placed on the pallet stack automatically

Maximize production

• Counterweighted and frequency driven elevator table removes load stress from the drive motor, ensuring smooth transport and longer motor life
• Stainless steel, tapered stripper plate ensures stable transfer of layer onto load
• Elevator table is supported by crossbar reinforcing beams to reduce case friction and eliminate table load stress

Square layers for secure pallet loads

A rear layer retainer plate and two side layer squaring plates ensure that the layer is centered on the pallet. The layer is held firmly to retain it squarely during the deposit cycle.
